ACL Gravity Feed Oilers
The ACL Gravity Feed Oiler is used in all heavy-duty applications where a large oil capacity is needed and an adjustable rate of oil is required.
Feature
Toggle Switch
A three-position toggle switch provides easy on-off control and a flushing option to avoid dry start-ups. The knurled adjustment knob allows for easy fine tuning of drip rates. The switch is then threaded down to lock the adjustment knob in place for consistency.
Feature
Remote Mounting and Sight Window
The 3/4-16 mounting stud and 1/4-inch OD tubing connection provides the ability to remote mount the reservoir and use a 1/4-inch OD tube to connect to an S Series Applicator Bracket with brush applicator. The sight window allows you to visually see the drip you are setting.
Additional Features
- Dependable Design
Silver brazing of all brass construction provides long life and leak proof design
- Durable
Clear lacquer finish resists corrosion
- Heavy Wall Reservoir
Acrylic reservoir versions have heavy walls for long life in applications to 165º F. Heavy wall heat resistant glass reservoirs and sights providing service in temperatures to 250º F.
Other Specs
| Model | Description | Capacity | Reservoir | Connection | Dim A (in) | Dim B (in) |
|---|---|---|---|---|---|---|
| 32016 | ACL Oiler | 1 pt | Acrylic | 3/4-16 mounting stud | 4-7/16 | 5-5/16 |
| 32032 | ACL Oiler | 1 qt | Acrylic | 3/4-16 mounting stud | 4-7/16 | 8-11/16 |
| 32080 | ACL Oiler | 2.5 qt | Acrylic | 3/4-16 mounting stud | 5-11/16 | 10-13/16 |
| 32081 | ACL Oiler | 1 gal. | Acrylic | 3/4-16 mounting stud | 5-11/16 | 15-7/8 |
| 32117 | ACL Oiler | 1 pt | Glass | 3/4-16 mounting stud | 4-7/16 | 5-5/16 |
| 32133 | ACL Oiler | 1 qt | Glass | 3/4-16 mounting stud | 4-7/16 | 8-11/16 |
| 32181 | ACL Oiler | 2.5 qt | Glass | 3/4-16 mounting stud | 5-11/16 | 10-13/16 |
Description
Capacity
Reservoir
Connection
Dim A (in)
Dim B (in)
Description
Capacity
Reservoir
Connection
Dim A (in)
Dim B (in)
Description
Capacity
Reservoir
Connection
Dim A (in)
Dim B (in)
Description
Capacity
Reservoir
Connection
Dim A (in)
Dim B (in)
Description
Capacity
Reservoir
Connection
Dim A (in)
Dim B (in)
Description
Capacity
Reservoir
Connection
Dim A (in)
Dim B (in)
Description
Capacity
Reservoir
Connection
Dim A (in)
Dim B (in)
-
Max. Operating Temp.Glass 250° F Continuous
Acrylic 165° F Continuous -
ReservoirHeavy Wall Heat Resistant Glass
Heavy Wall Acrylic Plastic -
Oil SightHeavy Wall Heat Resistant Glass
Heavy Wall Acrylic Plastic -
GasketBuna-N
-
MaterialBrass
-
FinishLacquered Satin Finish
-
Needle ValveBrass
